PDF-800-C12

  • Brand:

    POWERLD
  • Item NO.:

    PDF-800-C12
  • Wattage (W):

    800
  • Input:

    90Vac~264Vac
  • Output:

    12
  • PFC:

    Y
  • Conformal Coating:

    Y
  • Approval:

    N
  • Dimension:

    226×116.5×41mm
  • Product Detail

MODEL

PDF-800-C12

OUTPUT

DC Output

12V

5.0V

4812V

32V

Rated Current (90~175Vac)

54A

Rated Current (176~264Vac)

67A

Ripple and Noise Note 2

0~50℃

≤100mV

-20~0℃

≤100mV

Voltage ADJ.  Range

11.4~12.6V

Voltage Accuracy

±2%

±2.0%

±2.0%

±1.0%

±1.0%

±2.0%

±1.0%

Line Regulation

±0.5%

±0.5%

±0.5%

±0.3%

±0.2%

±0.2%

±0.2%

Load Regulation

±2%

±1.0%

±1.0%

±0.5%

±0.5%

±1.0%

±0.5%

Set-up Time

≤8S (220Vac input, Full load)

Hold up Time

≥5mS (220Vac input, Full load)

Temperature Coefficient

±0.03%/℃

Overshoot and Undershoot

<5.0%

INPUT

Voltage Range

90Vac~264Vac

Frequency Range

47Hz--63Hz

Power Factor(Typical)

PF0.98/230VAC     PF0.99/115VAC     Full Load

Efficiency ( Typical)

85% @230Vac,67A.

AC Current (max.)

10 A

Inrush Current (Typical)

<30A@230Vac       Cold start

Leakage Current

Input—output: 0.25mA     Input—PG: 3.5mA

PROTECTION

Over Load

74~87A, Constant current, auto recovery

Over power

900~980W, Constant current, auto recovery

Over Voltage

14~16V, Constant voltage, auto recovery

Over Temperature

105+5(detect on Mosfet temperature);shut down,auto recovery after the temperature goes down to85

Short Circuit

Long-term mode, constant current, auto recovery

ENVIRONMENT

Operating amb. Temp. & Hum.

-20℃~60℃;  20%~90%RH  No condensing  (refer to derating curve)

Storage Temp. & Hum.

-40℃~85℃;  10%~95%RH  No condensing

SAFETY &EMC

(Note 3)

Safety Standards

UL60950, EN60950

Withstand Voltage

Primary-Secondary: 3.0KVac/10mA .Primary-PG:1.5KVac/10mA. Secondary-PG: 0.5KVac/10mA.

Isolation Resistance

10M ohms

EMI Conduction&Radiation

Compliance to EN55022 Class A

Harmonic Current

Compliance to EN61000-3-2,Class D

EMS Immunity

Compliance to EN61000-4-2,3,4,5,6,8,11;

OTHERS

MTBF (MIL-HDBK-217F)

More than 200,000Hrs (25℃, Full load)

DC OK

4V-6V

Dimension  (L*W*H)

226×116.5×41mm

Packing

12PCS/CTN, 16.8KGS, 0.04CBM

Cooling method

Fored air cooling(Built-in fan,the fan speed is controlled by load and internal temp.)

NOTE

1.      All parameters NOT specially mentioned are measured at rated input, rated load and 25℃ of ambient temperature.

2.      Measured at 20MHz of bandwidth by using a 12” twisted pair-wire terminated with a 0.1 uF & 47uF parallel capacitor.

3. The power supply is considered as a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies” on http://www.powerld.com.cn.
